Versatile. Ultra-simple. Unbelievable range.
915 MHz remote camera control that feels like magic.
Versatile. Ultra-simple. Unbelievable range. 915 MHz remote camera control that feels like magic.
zero configuration.
massively configurable.
zero configuration.
massively configurable.
Plug bitbox directly into a tablet or camera with USB-C Ethernet support.
Set your camera’s IP to match the network and you’re done.
Use your existing network with no additional hassle.
Not even a config page. No more mesh units. No dongle required.
Plug bitbox directly into a tablet or camera with USB-C Ethernet support. Set your camera’s IP to match the network and you’re done. Use your existing network with no additional hassle. Not even a config page. No more mesh units. No dongle required.
pairing couldn't
be simpler.
pairing couldn't
be simpler.
bitbox includes multiple antenna options suitable for most camera builds. Want to expand the system with rental or borrowed units? Just press a button on each radio.
bitbox includes multiple antenna options suitable for most camera builds. Want to expand the system with rental or borrowed units? Just press a button on the main radio.
batteries not included.
batteries not included.
With a sub-5 second boot time and minimal power draw, bitbox is a feat of efficiency. You won't need them.
With a sub-5 second boot time and minimal power draw, bitbox is a feat of efficiency. You won't need them.
go loooooooooooong.
bitbox gives you camera control with unreal range,
even in the most congested RF spectra on Earth.
We're talking 3 city blocks in Manhattan and way,
way further in less-crowded areas.
bitbox gives you camera control with unreal range, even in the most congested RF spectra on Earth. We're talking 3 city blocks in Manhattan and way, way further in less-crowded areas.
you'll forget
it’s even there.
With a svelte footprint and easy operation,
bitbox will transform how you work without compromising
precious real estate on the cart or the camera.
With a svelte footprint and battery-free operation, bitbox will transform how you work without compromising precious real estate on the cart or the camera.
by pros.
for pros.
We could have crammed an off-the-shelf board into a case and called it a day, but we didn't. bitbox was designed from scratch by cinema professionals with their own carts, builds, and workflows in mind. We optimized every aspect for maximal results with extreme simplicity and reliability.
bitbox is ready to deploy across a wide range of cameras
and accessories.
All trademarks, logos and brand names are the property of their respective owners. All company, product and service names used in this website are for identification purposes only. Use of these names, trademarks and brands does not imply endorsement.
it’s getting better
all the time.
We’re hard at work on tablet-based hardware options and a production router for managing camera and control IP schemes.
Want to get involved in testing?
Join our Discord community.
This just the start.
it’s getting better
all the time.
We’re hard at work on tablet-based hardware options and a production router for managing camera and control IP schemes.
Want to get involved in testing?
Join our Discord community.
This just the start.
no strings attached.
Owning bitbox is as hassle-free as using it.
No software, subscription, or proprietary hand unit needed.
Want to integrate bitbox radios into your existing equipment?
Drop us a line and we’ll gladly consult.
no strings attached.
Owning bitbox is as hassle-free as using it.
No software, subscription, or proprietary hand unit needed.
Want to integrate bitbox radios into your existing equipment?
Drop us a line and we’ll gladly consult.
specifications
Dimensions
• 81.13 mm x 51.2 mm x 21.8 mm (3.19 x 2.01 x 1.38 inches)
Weight
• Less than 100g / 3.5oz
Materials
• Black anodized 6061 & 7075 aluminum housing
Materials
• Sustainable plastic button & switch elements
MECHANICAL INTERFACE
Built-in:
• 1/4-20 threaded hole with ARRI and SmallHD anti-rotation patterns
• 15mm grid of ten M4 mounting holes
• 20mm grid of seven M2.5 mounting holes (compatible with Wooden Camera mini accessory rails)
HUMAN INTERFACE
• Pairing Button
• Power Light
• Signal Level Lights
• Base Station / Remote Radio Selector Switch with Pairing Light
CONNECTORS
Antenna
• Field-replaceable antenna (don't let the Dolly Grip ruin your day)
2-pin Lemo 0b
• 11-36 volt power input, polarity agnostic
USB-C
• 5 volt power input or output
USB-C
• USB Ethernet chipset (connect to devices without Ethernet ports)
USB-C
• Radio diagnostics, advanced configuration, and firmware upgrade
Ethernet Jack
• Gigabit Ethernet
Input
• 11-36V (via 2-pin Lemo 0b) or 5V via USB-C
• 3W max, 1.8W average (when not supplying USB-C power to external device)
Output
• 5V via USB-C (when powered via 2-pin Lemo)
• 1.5A max (sufficient to charge an iPad mini on full brightness)
